Multifunctional Computerized Tape Cutting Machine

  • Model:KS-B95 Series
  • Blade Type:Various Types
  • Max. Width:95mm
  • Net. Weight:78Kg
  • Dimension:820×570×780mm
  1. This series of belt cutting machine has the characteristics of high speed and high precision. It adopts belt feeding instead of traditional roller feeding. There is no indentation on the surface of the material, and the feeding length is more accurate.

  2. Color touch screen operation interface, program storage function, and 4 different models to choose from, covering rotation angle cutting, hole punching, hot and cold knife cutting, care label cutting and other functions.

  3. The hole punching function can be selected, and the punching position can be set in the program freely.

  4. The machine can also be equipped with an optional color sensor for cutting washed care labels, which can accurately identify the label's separation line and cut it from the designated line accurately.

Download: (1)
  1. KS-B951: The feature of this machine is that the cutter head can be rotated, and the angle of rotation can be set in the program, so it can cut bevels, such as trapezoids, parallelograms, etc.

  2. KS-B952: This is a hot knife tape cutting machine with automatic stacking function, the finished tapes will be clamped by the cylinder automatically, and stop automatically when the set number is reached, so the specified number of tapes can be collected neatly into a bundle.

  3. KS-B953: This is a cold and hot knife tape cutting machine, the heating function can be turned on or off freely in the program, so it has a wide range of applications.

  4. KS-B954: This is cold knife tape cutting machine, the other functions are similar to KS-B953. The auxiliary feeder behind it is optional, the machine does not include this device by default.


KINGSING

KINGSING

KINGSING

KINGSING

ModelKS-B951KS-B952K-B953KS-B954
Blade TypeHot KnifeHot KnifeCold and HotCold Knife
Hole PunchOptionalOptionalOptionalOptional
Rotary AngleYes
NoNo
No
Stack FunctionNo
YesYesYes
Care LabelNoPotionalOptionalOptional
Tape Width
45~60mm
95mm
95mm95mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
